Vendor: ACOPOWER
SKU: WVC-350
Availability: In Stock
$199.00
$199.00
Terms & conditions
Description
Description
x

Product parameter

model WVC-350(R3)
Maximum input power 1*350W
Output voltage mode 120V/230V automatic switching
Solar panel open circuit voltage range 30-60V
Peak power tracking voltage 22-60V
Min/Max starting voltage 22-60V
Maximum DC short circuit current 18A
Maximum input working current 16A
Output parameters @120V @230V
Peak output power 350Watt 350Watt
Rated output power 320Watt 320Watt
Rated output current 2.9A 1.5A
Rated voltage range 80-160VAC 180-280VAC
Rated frequency range 48-51Hz/58-61Hz 48-51Hz/58-61Hz
Power Factor >99% >99%
Number of circuit connections per string 15 sets (single phase) 25 sets (single phase)
Output efficiency @120V @230V
Static MPPT efficiency 99.5% 99.5%
Maximum output efficiency 95% 95%
Power loss at night <1w <1w
Total harmonic distortion <5% <5%
Appearance and technical characteristics
range of working temperature -40 ℃ to +65 ℃
Size(mm) 165*176*38
net weight 0.82kg
waterproof level IP65
Cooling method Self-cooling
Communication mode 433Mhz communication mode
Power transmission mode Reverse transmission, load priority
surveillance system Mobile App, Browser
Electromagnetic Compatibility EN50081.Party EN50082.Party 1
Grid disturbance EN61000-3-2 Safety Regulation 62109
Grid detection DIN VDE 0126
certificate CE, CEC, appearance patent
Package weight
specification Single (packaging) FCL (15 units)
Gross weight 1.28Kg 19.5Kg
Size(mm) 245*202*60 450*395*345
Downloads
Downloads
x

WVC-350 Manual
